Buderus 7738000111 G215 Series 117 Input MBtu Logano Thermostream Oil-Fired Boiler (Knockdown)

SKU
G215/3

In Stock. Ships in 1-7 Business Days.

Retail : $3,432.00 - $550.15 =
$2,881.85 You Save (16%)
117,000

- +
117,000

Product details

Its Construction Consists of a Full Size Burner Swing Door for Easy Access to the Boiler Interior and Burner and a Deluxe, Heavy Gauge Blue Enameled Jacket for a Clean Finished Appearance; Eliminates "Hot and Cold Spots" in the Boiler; Minimizes Stresses Normally Caused by Rapid Temperature Changes; Operates at Low Return Water Temperatures; Balances Water Flow through All Boiler Sections; EnergyStar; Rear Tappings and Flue Connection to Streamline Appearance; Baffles and Clips for Adjusting Stack Temperatures; Full Swing Burner Door Hinged on Either the Left or Right Allowing for Easy Access; Front Access Plugs Permit Flushing of the Boiler's Interior; Buderus Offers a Full Range of High Efficiency Indirect Water Tanks to Compliment Your Boiler

FEATURES
  • Thermostream Boiler
  • Type Oil Gas Combination, Hot Water
  • Applicable Standard ASME H, CSA (Canada and US), AHRI, MEA, CRN
  • Supply Connection 1-1/2"
  • Return Connection 1-1/2"
  • DOE Heating Capacity 134 MBH
  • Net IBR Rating 117 MBH
  • AFUE Rating 86.3 Percent
  • Firing Rate 1.1 GPH
  • Boiler Dimensions 23-1/2" Length x 26-1/4" Width x 34-3/4" Height
  • Boiler Height Including Draft Hood 41
  • Boiler Material Cast Iron
  • Chimney Size 6" Diameter x 20' Height
  • Water Content 12.9 Gallon
  • Burner Type Carlin, Riello, Beckett
  • Vent Size 6"
  • Mounting Type Floor Mount
  • Relief Valve Details Supplied
  • Pressure Rating 58 PSI
  • Inclusions/Features Rear Tappings and Flue Connection to Streamline Appearance, Baffles and Clips for Adjusting Stack Temperatures, Heavy Gauge Blue Enameled Jacket for Durability and Attractiveness, Full Swing Burner Door Hinged on Either the Left or Right Allowing for Easy Access, Front Access Plugs Permit Flushing of the Boiler's Interior
  • Application Residential
  • Number of Section 3
  • Fire Box Volume 1.35 Cubic Foot
  • Fire Box Dimension 16-3/4" Depth
  • Dry Weight 400 Lb
Bosch
See All Bosch Products

Specification Sheet

Basic Information
MPN ? Manufacturer Part Number 7738000111
Manufacturer Bosch
Series ? A manufacturer's grouping of items that match, coordinate, or complement each other. G215 Series
Dimensions and Measurements
BTU Input 117,000
Height (Inches) ? The vertical measurement from bottom to top, measured in inches. 34-3/4"
Length (Inches) ? The distance of the product's longest side, measured in inches. 23-1/2"
Width (Inches) ? The horizontal measurement from left to right, measured in inches. 26-1/4"
Characteristics and Features
Material ? The material(s) used in the construction of the product. Cast Iron
Venting Atmospheric or Direct
