Weil-Mclain 386-701-029 WTGO-4R 140 Input MBtu 86.2% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)

SKU
386701029

In Stock. Ships in 1-7 Business Days.

Click Here for Shipping Cost by Destination
Retail : $4,723.00 - $991.83 =
$3,731.17 You Save (21%)
140,000
Weil-Mclain 386-701-028 WTGO-3L 98 Input MBtu 86.4% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Weil-Mclain 386-701-027 WTGO-3R 112 Input MBtu 86.2% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Selected
Weil-Mclain 386-701-029 WTGO-4R 140 Input MBtu 86.2% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Weil-Mclain 386-701-030 WTGO-5R 168 Input MBtu 86.1% AFUE Cast Iron Oil-Fired Water Boiler with T-007 Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Weil-Mclain 386-701-031 WTGO-6R 196 Input MBtu 86.1% AFUE Cast Iron Oil-Fired Water Boiler with T-007 Circulator Series 4 - Chimney Vent (Burner Sold Separately)
selected
selected

- +
140,000
Weil-Mclain 386-701-028 WTGO-3L 98 Input MBtu 86.4% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Weil-Mclain 386-701-027 WTGO-3R 112 Input MBtu 86.2% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Selected
Weil-Mclain 386-701-029 WTGO-4R 140 Input MBtu 86.2% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Weil-Mclain 386-701-030 WTGO-5R 168 Input MBtu 86.1% AFUE Cast Iron Oil-Fired Water Boiler with T-007 Circulator Series 4 - Chimney Vent (Burner Sold Separately)
Weil-Mclain 386-701-031 WTGO-6R 196 Input MBtu 86.1% AFUE Cast Iron Oil-Fired Water Boiler with T-007 Circulator Series 4 - Chimney Vent (Burner Sold Separately)
main product photo

Product details

Weil-Mclain 386-701-029 WTGO-4R 140 Input MBtu 86.2% AFUE Cast Iron Oil-Fired Water Boiler with T-007e Circulator Less Burner Series 4 - Chimney Vent

FEATURES
  • Oil-fired water boiler with cast iron sections
  • High capacity / high efficiency tankless heater
  • Quick open top and swing-away burner door with full chamber access increases visibility for inspection and servicing
  • Includes factory-wired circulator, service switch and Weil-McLain exclusive captured elastomer seals for added reliability
  • Recessed target wall design protects unit from flue brushes
  • Two flue outlets- rear and top - for complete venting flexibility
  • Available assembled or as a knockdown for installation areas with limited space

WTGOCAST IRON OIL BOILER

blanco/WTGO

BOILER

  • Factory tested and assembled cast iron section assembly (jacket and collector hood are not assembled on 7, 8 and 9 section blocks)
  • Tankless heater (Packaged* units) or tankless opening cover plate (SemiPackaged* & Knocked-Down* units)
  • Insulated steel jacket
  • Aluminized steel flue collector hood with flue cap on top outlet
    • (convertible to rear outlet)
  • Swing-away burner mounting door
  • Refractory blanket and target wall in combustion area
  • Circulator (when ordered)
  • Sizes 3–4: Taco 007e
  • Sizes 5–6: Taco 007
  • Combination limit control, tankless heater control and LWCO with integrated service switch
  • Two vent pipe brackets
  • Pressure / temperature gauge
  • 30 PSI ASME relief valve (boiler sections tested for 50 PSIG working pressure)
  • Drain valve
  • Barometric damper

OPTIONAL EQUIPMENT:

  • High-efficiency flame-retention oil burner (Beckett AFG, Carlin EZ or Riello). Specify 2-Stage fuel unit (optional, Beckett) if required
  • Vent damper kits

LIMITED TRANSFERABLE WARRANTY:

  • Residential: 20 Years Heat Exchanger; 2 Years Parts
  • Commercial: 10 Years Heat Exchanger; 1 Year Parts
Weil-McLain
See All Weil-McLain Products

Specification Sheet

Product Specifications Installation Manual
Basic Information
MPN ? Manufacturer Part Number 386-701-029
UPC / GTIN 672619218710
Manufacturer Weil-McLain
Series ? A manufacturer's grouping of items that match, coordinate, or complement each other. WTGO Series 4
Dimensions and Measurements
Weight ? Weight 610.00
BTU Input 140,000
AFUE 86.2%
Height (Inches) ? The vertical measurement from bottom to top, measured in inches. 35-5/8"
Length (Inches) ? The distance of the product's longest side, measured in inches. 16-7/8"
Width (Inches) ? The horizontal measurement from left to right, measured in inches. 20-1/4"
Characteristics and Features
Material ? The material(s) used in the construction of the product. Cast Iron
Boiler Type Residential
Fuel Type Oil
Venting Chimney Vent
