Heat-Timer 928074-00 4" Double Seated 2 Way Motorized Valve Vacuum Steam Heating Service

SKU
HTM92807400

In Stock. Ships in 1-7 Business Days.

Retail : $6,340.00 - $3170 =
$3,170.00 You Save (50%)
- +

Product details

Vacuum Steam Heating. 2-way valves can modulate the flow of sub-atmospheric steam from the boiler or other source into a steam distribution system. Actuators are equipped with a position feedback signal. A typical example of this type of application would be using vacuum steam to heat radiators in a building. When the control, such as the SRC Platinum, calls to put heat into the system, the 2-way valve partially modulates open and steam flows into the radiators based on the outdoor air temperature. Then when the control determines that sufficient heat has entered the radiators, the control marginally closes the 2-way valve reducing the flow of steam.

FEATURES
  • Valves come complete with motors and transformers
  • Designed to withstand the Press. and Temp. demands of most types of HVAC systems
  • Class IV Shutoff
  • Long Life Multi-Stacked EPDM Rubber Packing means less air infiltration
  • Valve motor has infinite adjustability between fully open and fully closed
  • High performance actuators with Position Feedback (Approx. 2 Minute Motor Speed)
  • Maximum Operating Pressure 55 psi at 302°F
  • Equal% Balanced Port for continuous flow even at the smallest opening
  • Iron body for longevity and durability
  • Two-Way, Double Seated, Bronze/SS Trim
  • 13.8" FTF; 14.4" High (Pipe Centerline to Actuator Top)
  • ANSI 125# Flanged Connections
Heat-Timer
See All Heat-Timer Products

Specification Sheet

Basic Information
MPN ? Manufacturer Part Number 928074-00
UPC / GTIN 684120202539
Manufacturer Heat-Timer
Dimensions and Measurements
Height (Inches) ? The vertical measurement from bottom to top, measured in inches. 14.4"
Weight ? Weight 129.00
Characteristics and Features
Valve PSI 55 PSI
