Downloads
- CAD Front (dwg)
- CAD Left (dwg)
- CAD Right (dwg)
- CAD Top (dwg)
- Care Cleaning (pdf)
- Cutout Template (dxf)
- Installation Instructions (pdf)
- Specification Sheet (pdf)
- Warranty (pdf)
Specifications
| Material |
Stainless Steel |
|---|---|
| Installation Type |
Drop-in |
| Features |
Quick-Clip Mounting System |
| Gauge |
18 |
| Sound Deadening |
Bottom only pads |
| Number of Bowls |
2 |
| Minimum Cabinet Size |
36" |
| Dimensions |
L:Â 33" W:Â 22" H:Â 5-1/2" |
| Bowl 1 Dimensions |
L:Â 13-1/2" W:Â 16" H:Â 5-1/8" |
| Bowl 2 Dimensions |
L:Â 13-1/2" W:Â 16" H:Â 5-1/8" |
| Drain Size |
3-1/2" |
| Drain Size 2 |
3-1/2" |
| Shipping Dimensions |
L:Â 37-3/4" W:Â 26-1/4" H:Â 9-1/2" |
| Shipping Weight |
23Â LBS |
| Made or Assembled USA |
made |
| Family |
Lustertone Classic |
| ADA |
Yes |
| Code Compliance Sinks |
ADA & ICC A117.1 ASME A112.19.3/CSA B45.4 Buy American Act |
| Room |
Kitchen |
Description
An Elkay Lustertone Classic stainless steel sink looks as great on day 3,000 as it does on day one. The rich, uniform grain is scratch resistant for heavy-duty use, whether it's a kitchen sink or a prep, bar, laundry or commercial sink. Light scratches, which occur with everyday use, naturally blend into the finish of this durable sink with time. Deeper scratches are repairable with an Elkay stainless steel restoration kit. Available in ADA depths.
Features
- ADA COMPLIANT: Product is ADA compliant when properly installed.
- REPAIRABLE FINISH: Finish is scratch resistant to heavy-duty use. Deep scratches are repairable. Lustrous grain reflects light evenly for high shine.
- DROP-IN INSTALLATION: Sink is designed for drop-in installation to make the sink a focal point of your room.
- DOUBLE BOWLS OF EQUAL SIZE: Conveniently use bowls independently for washing, soaking, rinsing, drying and other household tasks.
- 18-GAUGE STAINLESS STEEL: Highest quality 18-gauge thickness and Type 304 stainless steel for lasting durability, performance and lustrous beauty.
- SOUND GUARD® TECHNOLOGY: Large pads enhance sound-deadening performance for a quieter time at the sink.
- QUICK-CLIP MOUNTING SYSTEM: Quickly and securely install sink from above the counter with a series of clips that attach to laminate countertops.
- OFFSET DRAIN: Drain placement provides more usable space on the bottom of the sink and in the cabinet below.
- MADE IN THE USA: This Elkay product is proudly made in the USA.
- DRAIN OPENING: Sink drain opening measures 3-1/2".
Ratings & Reviews
Reviews
★★★★★ No rating value Be the first to review this product
â–¼ Rating Menu Filter by Rating
Filter by Rating 1 star
2 stars
3 stars
4 stars
5 stars
Active Filters
- 1 star ✘ Remove Filter
- 2 stars ✘ Remove Filter
- 3 stars ✘ Remove Filter
- 4 stars ✘ Remove Filter
- 5 stars ✘ Remove Filter
- Clear All ✘ Clear All Filters
Questions
Ask a question
1–2 of 2 Questions
Sort by: â–¼ Menu
Newest questions
-
♂
grace
· a month ago Â
What facet and handles for ADA can be used on this sink that has 3 holes. You are showing a single hole facet as an accessory.
1 answer
Originally posted on Elkay Lustertone Classic Stainless Steel 33" x 22" x 5-1/2", Equal Double Bowl Drop-in ADA Sink
-
♂
Elkay_Expert
· a month ago Â
Thank you for your question on the Elkay LRAD332255 Lustertone Classic Stainless Steel Equal Double Bowl Drop-in ADA Sink. I have included a link below that will take you to our ADA Kitchen faucets that require three faucet holes.
https://www.elkay.com/products/faucets/application/ada.html?hole_drillings=1136&product_list_limit=45&room_designation=1205
Helpful?
Yes · 0 0 people found this answer helpful. Click to agree. No · 0 0 people did not find this answer helpful. Click to agree.
Report
-
♂
-
♂
ahutton
· 8 months ago Â
does the LRAD2918653 have the elkey perfect drain and can i use standard 3 1/2 in drain baskets and disposal flanges or do i have to use the elkey perfect drain baskets and disposal flange?
1 answer
Originally posted on Elkay Lustertone Classic Stainless Steel 29" x 18" x 6-1/2", 3-Hole Equal Double Bowl Drop-in ADA Sink
-
♂
Elkay_Expert
· 8 months ago Â
Thank you for your question on the Elkay LRAD2918653 Lustertone Classic Stainless Steel Equal Double Bowl Drop-in ADA Sink. No, this model does not include Perfect Drain. You will be able to use any standard 3-1/2" drain like our Elkay LK99 Deluxe 3-1/2" Drain Type 304 Stainless Steel Body, Strainer Basket Rubber Seal and Tailpiece or Elkay LKAD35 3-1/2" Drain Fitting" Stainless Steel Body, Strainer Basket and Offset Tailpiece.
Helpful?
Yes · 0 0 people found this answer helpful. Click to agree. No · 0 0 people did not find this answer helpful. Click to agree.
Report
-
♂
